The Isuzu GIGA 6X4 10 cubic meter foam fire truck is based on the Isuzu GIGA 6X4 chassis, with a gross vehicle weight of 35 tons and a wheelbase of 4800+1370mm. It is equipped with an Isuzu 6WG1-TCG62 520hp engine and a Fast 12-speed transmission. The front of the superstructure houses the equipment compartment, the middle section contains an 8000L carbon steel water tank and a 2000L stainless steel foam tank, and the rear is the pump room, equipped with a CB10/140-XZ fire pump, control panel, fire hoses, firefighting equipment, etc. A PL8/64 fire monitor is located on the roof.

The Isuzu 12000L fire sprinkler truck uses an Isuzu FVZ GIGA 6X4 chassis with a 4650+1370mm wheelbase. It is equipped with an Isuzu 6HK1-TCG60 engine and a FAST 9-speed transmission. The front of the superstructure houses the pump house, which contains a CB10/60-RS fire pump and a control panel. Behind the pump house is a 12-cubic-meter carbon steel water tank. The rear features a work platform with a toolbox, side sprinklers, a ladder at the rear of the tank, a level gauge, right-side sprinkler heads, a removable top guardrail, and a PS8/50W fire monitor.

This Isuzu 3cbm water tanker fire truck is based on an Isuzu 100P 4x4 double-cab chassis with a 3360mm wheelbase. It is equipped with an Isuzu 4KB1-TCG60 engine and an MSB 5-speed gearbox. The front of the superstructure houses the equipment compartment, the middle section contains a 300L carbon steel water tank, and the rear is the pump room, equipped with a CB10/60-XZ fire pump, control panel, fire hoses, firefighting equipment, etc. A PS8/30W fire monitor is mounted on the roof.

The Isuzu GIGA 6X4 10 cubic meter foam fire truck is based on the Isuzu GIGA 6X4 chassis, with a wheelbase of 4600mm+1370mm. It is equipped with an Isuzu 6UZ1-TCG61 engine and a Fast 12-speed transmission. The front of the superstructure houses the equipment compartment, the middle section contains an 8500L carbon steel water tank and a 1500L stainless steel foam tank, and the rear is the pump room, equipped with a CB10/60-XZ fire pump, control panel, fire hoses, firefighting equipment, etc. A PL8/48 fire monitor is located on the roof.

The Isuzu GIGA 6X4 10 cubic meter foam fire truck is based on the Isuzu GIGA 6X4 chassis, with a wheelbase of 4600mm+1370mm. It is equipped with an Isuzu 6UZ1-TCG61 engine and a Fast 12-speed transmission. The front of the superstructure houses the equipment compartment, the middle section contains an 8500L carbon steel water tank and a 1500L stainless steel foam tank, and the rear is the pump room, equipped with a CB10/60-XZ fire pump, control panel, fire hoses, firefighting equipment, etc. A PL8/48 fire monitor is located on the roof.

The Isuzu FVR 6 cubic meter foam fire truck uses an Isuzu FVR chassis with a 4500mm wheelbase. It is equipped with an Isuzu 6HK1-TCL engine, a Fast 8-speed transmission, a 5-ton carbon steel water tank (with anti-corrosion treatment), a 1-ton 304 stainless steel foam tank, a Shanghai Xiongzhen CB10/40 low-pressure fire pump (rear-mounted pump room), a Chengdu West PL32 fire monitor, and a 30-meter medium-pressure hose reel in the pump house.

The Isuzu GIGA 4.5 CBM foam fire truck uses the Isuzu GIGA 4x2 Class II fire truck chassis, with a 4600mm wheelbase, an Isuzu 6UZ1-TCG50 engine, and a FAST 12-speed gearbox. The front of the superstructure houses the equipment compartment, with a 4 cubic meter carbon steel water tank and a 500L stainless steel foam tank in the middle. The rear houses the pump room, equipped with a CB10/60-RS fire pump, control panel, fire hoses, and a PL8/48 fire monitor mounted on the roof.

The Howo TX 4x2 7.5 cubic meter foam fire truck uses the Howo TX chassis with a 4700mm wheelbase. It is equipped with a Weichai WP4.6NQ240E62 engine and a Sinotruk HW95508STCL gearbox. The front of the superstructure is an equipment box for storing auxiliary firefighting equipment. The middle section contains a 5.5 cubic meter carbon steel water tank and a 2 cubic meter stainless steel foam tank. The rear pump room is equipped with a CB10/40-LC(BS) fire pump, control panel, firefighting equipment, PL8/32 fire monitor on the tank top, and two European standard manholes.

The Fire Truck Foam Cannon PL48 is a manual fire monitor that can spray both foam and water. It has a rated flow rate of 48 L/s, a rated pressure of 0.8 MPa, a water spray range of ≥70 m, and a foam spray range of ≥60 m. The monitor can rotate 360° horizontally and has an elevation angle of -30° to 70°, offering flexible operation.
